2500 series mechanical seal,High temperature and corrosion resistance ,11mm-45mm
| Model NO. | EK-2500 |
| Balance | Unbalanced |
| Standard | DIN24960, ISO3069, GB6556 |
| Specification | Inner Diameter 20 mm to 100 mm |
| Packaging Details | Carton |
| Payment Terms | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Delivery Time | 2/day |
Views:
We are here to solve your problems in a professional manner
Request ConsultationOur Mechanical seal model 2500 mechanical seal is availble in a wide varietyh of elastomers for handing practicay every industril fuid.All components are held togther by a snap ring in a unized construction design and can be repaired easily on-site.We also can make changes as customers'requirement or totally design a new type of mechanical seal to meet clients'needs.
Operating Limits
Pressure:≤1.2 MPa
Temperature: -20°C~ +200ºC
Linear Speed:≤25m/s
Materials
Rotary Ring:SIC/TC
Stationary Ring:Carbon/SIC/TC
Elastomers:Viton
Springs:SS304/SS316
Metal Parts: SS304/SS316
Mediums
Clean water,sewage water,oil and other moderately corrosive fluids.
Customization
Changes of materials for getting other operating parameters are possible. Contact us with your requirements.
