802 series mechanical seal,Replacement for Crane 87 (EI/ EC) seal, Roplan RTH87/ R90 ,20mm-80mm
| Model NO. | EK-802 |
| Balance | Unbalanced |
| Standard | DIN24960, ISO3069, GB6556-94 |
| Specification | Inner Diameter:20 mm to 80 mm |
| Packaging Details | Carton |
| Payment Terms | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Delivery Time | 2/day |
Views:
We are here to solve your problems in a professional manner
Request ConsultationOur Mechanical seal model 802 is applied to fecal and submersible pumps for sewage, turbidwater or slightly aggressive liquids with solid particles.It can replace the seals for Crane 87 (EI/ EC) seal, Roplan RTH87/ R90.We also can make changes as customers'requirement or totally design a new type of mechanical seal to meet clients'needs.
Operating Limits
Pressure: ≤0.5 MPa
Temperature:-20°C~+180°C
Linear Speed:≤12m/s
Materials
Rotary Ring: SIC/TC
Stationary Ring: Carbon/SIC/TC
Elastomers: EPDM/VITON/NBR
Springs: SS304/SS316
Metal Parts: SS304/SS316
Mediums
water,polluted water,oil and minor corrosive liquid.
Customization
Changes of materials for getting other operating parameters are possible. Contact us with your requirements.
