M2N series mechanical seal,Replacement for AESSEAL T07D ,BURGMANN M2N ,10mm-38mm
| Model NO. | EK-M2N |
| Balance | Unbalanced |
| Standard | DIN24960, ISO3069, GB6556 |
| Specification | Inner Diameter: 10mm to 38mm |
| Packaging Details | Carton |
| Payment Terms | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Delivery Time | 2/day |
Views:
We are here to solve your problems in a professional manner
Request Consultationour Mechanical seal model M2N can Replace AESSEAL T07D ,BURGMANN M2N,which is widely used for Hecker HN 400A and other kinds of pumps. The normal material combination include carbon/ceramic/nbr/ss304,resincarbon/ceramic/nbr/ss304/,sic/sic/nbr/ss304,tc/tc/nbr/ss316 and so on. we also can make changes as customers'requirement or totally design a new type of mechanical seal to meet clients'needs.
Operating Limits
Pressure:≤1 MPa
Temperature:-20°C~+180°C
LinearSpeed: ≤15m/s
Materials
Rotary Ring:Carbon/SIC/TC
Stationary Ring:99%Ceramic/SIC/TC
Elastomers: NBR/EPDMVITON/PTFE
Springs:SS304/SS316
Mediums
oil, water, and weak corrosive mediums.
Customization
Changes of materials for getting other operating parameters are possible. Contact us with your requirements.
