SC-A05 series mechanical seal,Replacement for AESSEAL(BDFI& BDFC) ,24mm-70mm
| Model NO. | EK-SC-A05 |
| Balance | Unbalanced |
| Standard | ISO3069, GB6556, DIN24960 |
| Specification | Inner Diameter: 24 mm to 70 mm |
| Packaging Details | Carton |
| Payment Terms | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Delivery Time | 2/day |
Views:
We are here to solve your problems in a professional manner
Request ConsultationOur mechanical seal model SC-A05 is mainly applied in the pumps for Hecker HN 430N,CR,NBG,Grundfos,TP,NKGCLM,CRN and so on.It can replace the seals for AESSEAL(BDFI& BDFC).We also can make changes as customers'requirement or totally design a new type of mechanical seal to meet clients'needs.
Operating Limits
Pressure:≤2.3 MPa
Temperature:-20°C~+200°C
Linear Speed:≤25m/s
Materials
Rotary Ring:SIC/TC/Carbon
Stationary Ring: SIC/TC
Elastomers: Kalrez/EPDM/VITON
Springs: SSS304/SS316
Metal Parts: SS304/SS316
Mediums
weak acid, weak alkalis, water and solvents.
Customization
Changes of materials for getting other operating parameters are possible. Contact us with your requirements.
