Model NO. EK-HG212
Balance Unbalanced
Standard ISO3069, GB6556, DIN24960
Specification Inner Diameter: 40 mm to 150 mm
Packaging Details Carton
Payment Terms L/C, D/A, D/P, T/T, Western Union, MoneyGram
Delivery Time 2/day

Views:

We are here to solve your problems in a professional manner

Request Consultation

Our mechanical seal model HG212 is mainly applied in the pumps for Laval,APV,Calpeda,Inoxpa,KSB,Lowara,Grundfos, Hilge, Ebara.It can replace the seals for Burgmann,John Crane,Roten,AESSEAL,Anga, Vulcan, Lidering, DIMER.We also can make changes as customers'requirement or totally design a new type of mechanical seal to meet clients'needs.

Operating Limits

Pressure:≤0.5MPa

Temperature:-20°C~+150°C

Linear Speed: ≤500 rmp

Materials

Rotary Ring: Glass Filled PTFE

Stationary Ring: Aluminium Oxide/SIC

Elastomers: PTFE

Spring: SSS304/SS316

Metal Parts: SS304 /SS316

Mediums

weak acid, weak alkalis, water and solvents.

Customization

Changes of materials for getting other operating parameters are possible. Contact us with your requirements.
