4701 series mechanical seal,Suitable for pumps of Hypo acid, alkali, acid, flocculent vegetable, chemical and so on ,16mm-55mm
| Model NO. | EK-4701 |
| Balance | Unbalanced |
| Standard | ISO3069, GB6556, DIN24960 |
| Specification | Inner Diameter: 16 mm to 55 mm |
| Packaging Details | Carton |
| Payment Terms | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Delivery Time | 2/day |
Views:
We are here to solve your problems in a professional manner
Request ConsultationOur mechanical seal model 4701 is mainly applied in the types of pumps of Hypo acid, alkali, acid, flocculent vegetable, chemical, HMC, swimming pool spring, water treatment spring, food additive, water, additive, sulfuric acid, soluble salt.The normal material combination is sic/sic/VITON/ss304.We also can make changes as customers'requirement or totally design a new type of mechanical seal to meet clients'needs.
Operating Limits
Pressure:≤0.3MPa
Temperature:-20°C~+80°C
Linear Speed:≤300 rpm
Materials
Rotary Ring: Carbon/SIC
Stationary Ring: Carbon/SIC
Elastomers: NBR/VITON
Springs: SSS304/SS316
Metal Parts: SS304 /SS316
Mediums
argon oxidation of Ca (OH) 2 (lime milk) acid, humic acid, humic liquid, chemical solution, lime milk chemical liquid, sulfuric acid, basin acid, nitric acid, acid, acetic acid.
Customization
Changes of materials for getting other operating parameters are possible. Contact us with your requirements.
