4702 series mechanical seal,Replacement for EA560D Burgmann, John Crane 6,AESSEAL B04 ,12mm-50mm
| Model NO. | EK-4702 |
| Balance | Unbalanced |
| Standard | DIN24960 |
| Specification | Inner Diameter:12 mm to 50 mm |
| Packaging Details | Carton |
| Payment Terms | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Delivery Time | 2/day |
Views:
We are here to solve your problems in a professional manner
Request ConsultationOur Mechanical seal model is applicable to the series pumps: Haigh, Hidrostal, Hilde, Inbeat,INOXInoxpa, Jabsco,Johnson, KSB, Lowara,Mouvex, Nissin,KSB, Lowara, Mouvex, Nissin,and so on.It can replace the seals for EA560D Burgmann, John Crane 6,AESSEAL B04.We also can make changes as customers'requirement or totally totally design a new type of mechanical seal to meet clients'needs.
Operating Limits
Pressure:≤0.3 MPa
Temperature:-20°C~+80°C
Linear Speed: ≤15m/s
Materials
Rotary Ring: Carbon /SIC /TC
Stationary Ring: Carbon / Ceramic/ SIC /TC
Elastomers: NBR/VITON
Springs: SS304 /SS316
Metal Parts: SS304 /SS316
Mediums
weak acid, weak alkalis, water and solvents.
Customization
Changes of materials for getting other operating parameters are possible. Contact us with your requirements.
