GX/GY series mechanical seal,Suitable for industrial pumps, chemical pumps and water pumps ,30mm-90mm
| Model NO. | EK-GX-GY |
| Balance | Unbalanced |
| Standard | DIN24250, ISO3069, GB6556, EN12756 |
| Specification | Inner Diameter:30 mm to 90 mm |
| Packaging Details | Carton |
| Payment Terms | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Delivery Time | 2/day |
Views:
We are here to solve your problems in a professional manner
Request ConsultationOur Mechanical seal model GX/GY is widely used in different types of industrial pumps, chemical pumps and water pumps.It has the superior quality of high temperature and corrosion resistance.The normal material combination is sic/sic/VITON/ss304.We also can make changes as customers'requirement or totally design a new type of mechanical seal to meet clients'needs.
Operating Limits
Pressure: (GX) ≤0.8 mpa/(GY)≤4MPa
Temperature: -0°C~ +180 ºC
Linear Speed:≤3000r/min
Materials
Rotary Ring:Ceramics/TC
Stationary Ring:SIC/TC
Elastomers:NBR//VITON
Springs:SS304/SS316
Metal Parts: SS304 /SS316
Mediums
oil, water, amorphism acid, alkali, and organic solvents.
Customization
Changes of materials for getting other operating parameters are possible. Contact us with your requirements.
