T1/FBC series mechanical seal,Replacement for AESSEAL P05U and JOHN CRANE 1 (US) ,0.75mm-3mm
| Model NO. | EK-T1-FBC |
| Balance | Unbalanced |
| Standard | ISO3069, GB6556, DIN24960 |
| Specification | Inner Diameter: 0.75 mm to 3 mm |
| Packaging Details | Carton |
| Payment Terms | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Delivery Time | 2/day |
Views:
We are here to solve your problems in a professional manner
Request ConsultationOur Mechanical seal model T1/FBC can Replace AESSEAL P05U and JOHN CRANE 1 (US). The normal material combination include carbon/ceramic/nbr/ss304,resin carbon/ceramic/nbr/ss304/,sic/sic/nbr/ss304,tc/tc/nbr/ss316 and so on. We also can make changes as customers'requirement or totally totally design a new type of mechanical seal to meet clients'needs.
Operating Limits
Pressure: ≤2.8MPa
Temperature:-30°C~+200°C
Linear Speed: ≤13 m/s
Materials
Rotary Ring:Carbon/SIC/TC
Stationary Ring:Ceramic/SIC/TC/SUS304
Elastomers:NBR/EPDM/VITON
Springs: SS304/SS316
Mediums
oil, water, and weak corrosive mediums.
Customization
Changes of materials for getting other operating parameters are possible. Contact us with your requirements.
