104 series mechanical seal,Replacement for Burgmann, John Crane, Flowserve, Latty, Roten, Sealol ,16mm-120mm
| Model NO. | EK-104 |
| Balance | Unbalanced |
| Standard | JB/T1472 |
| Specification | Inner Diameter: 16 mm to 120 mm |
| Packaging Details | Carton |
| Payment Terms | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Delivery Time | 2/day |
Views:
We are here to solve your problems in a professional manner
Request ConsultationOur mechanical seal model 104 is designed for chemical pumps, screw pumps, oil pumps, and paper making equipment, mainly used in oil refining, chemical engineering, chemical product transportation, water treatment, chemical fiber and other industries.It can replace the seals for Burgmann, John Crane, Flowserve, Latty, Roten, Sealol.We also can make changes as customers'requirement or totally design a new type of mechanical seal to meet clients'needs.
Operating Limits
Pressure: ≤0.8 MPa
Temperature:-20°C~+150°C
Linear Speed: ≤15 m/s
Materials
Rotary Ring: SIC/TC
Stationary Ring: Carbon/SIC/TC
Elastomers:NBR/EPDM/VITON/PTFE
Springs: SS304/SS316
Metal Parts: Ss304/SS316/SS316L
Mediums
oil, water, amorphism acid, alkali, salt, and organic solvents.
Customization
Changes of materials for getting other operating parameters are possible. Contact us with your requirements.
