128 series mechanical seal,Replacement for W011U,AessealW07D/W07DM,FlowservePac-Seal ,20mm-75mm
| Model NO. | EK-128 |
| Balance | Unbalanced |
| Standard | ISO3069, GB6556, DIN24960 |
| Specification | Inner Diameter: 20 mm to 75 mm |
| Packaging Details | Carton |
| Payment Terms | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Delivery Time | 2/day |
Views:
We are here to solve your problems in a professional manner
Request ConsultationOur Mechanical seal model 128 series is applicable to the series pumps:SNM7N,Grundfos, Calpeda and another pumps.It can replace the seals for W011U,AessealW07D/W07DM,FlowservePac-Seal.We also can make changes as customers'requirement or totally totally design a new type of mechanical seal to meet clients'needs.
Operating Limits
Pressure: 0.8 MPa
Temperature:-20°C~+200°C
Linear Speed:≤15m/s
Materials
Rotary Ring: SIC/TC
Stationary Ring: Carbon/SIC/TC
Elastomers: NBR/EPDM/VITON
Springs: SS304
Metal Parts: SS304
Mediums
oil, water, amorphism acid, alkali, and organic solvents.
Customization
Changes of materials for getting other operating parameters are possible. Contact us with your requirements.
