MG13 series mechanical seal,Replacement for Burgmann MG13,AESSEAL B02,Flowserve Pac-Seal 193,ROTEN L3,Vulcan Type193,ANGA Al,Sterling SMG13,Hermetica 212 ,10mm-100mm
| Model NO. | EK-MG13 |
| Balance | Unbalanced |
| Standard | DIN24960, ISO3069, GB6556, EN12756 |
| Specification | Inner Diameter: 10 mm to 100 mm |
| Packaging Details | Carton |
| Payment Terms | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Delivery Time | 2/day |
Views:
We are here to solve your problems in a professional manner
Request ConsultationOur Mechanical seal model MG13 is applied in pumps: Alfa Laval,Ebara (3M,Dwo),Lowara,K5B(Etanorm, Etachromj,WILO(MVI,MHI,IPL/DPL),Grundfos (CD), Saer@Pj,and many others.It can replace the seals for Burgmann MG13,AESSEAL B02,Flowserve Pac-Seal 193,ROTEN L3,Vulcan Type193,ANGA Al,Sterling SMG13,Hermetica 212.We also can make changes as customers'requirement or totally design a new type of mechanical seal to meet clients'needs.
Operating Limits
Pressure: ≤1.4MPa
Temperature: - 20°C~+ 140°C
Linear Speed: ≤15 m/s
Materials
Rotary Ring: Carbon/SIC/TC
Stationary Ring: Al202/SIC/TC
Elastomers:NBR/EPDM/VITON
Springs: SS304/SS316
Metal Parts: SS304/SS316
Mediums
oil, water, and weak corrosive mediums.
Customization
Changes of materials for getting other operating parameters are possible. Contact us with your requirements.
