HRN series mechanical seal,Replacement for Burgmann(HRN),Roten(EHS3) ,18mm-100mm
| Model NO. | EK-HRN |
| Balance | Unbalanced |
| Standard | ISO3069, GB6556, DIN24960 |
| Specification | Inner Diameter: 18 mm to 100 mm |
| Packaging Details | Carton |
| Payment Terms | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Delivery Time | 2/day |
Views:
We are here to solve your problems in a professional manner
Request ConsultationOur mechanical seal model SC-A05 is mainly applied in Alfa Laval, Ebara, Lowala,KSB(Etanorm,Etachrom),WILO(MVI,MHl,IPL), Grfundfos(CDM),Saer(IP),CALPEDA(GM,MXS),HeckerHN 410SU.It can replaces for Burgmann(HRN),Roten(EHS3).We also can make changes as customers'requirement or totally design a new type of mechanical seal to meet clients'needs.
Operating Limits
Pressure:≤2.5MPa
Temperature:-20°C~+220°C
Linear Speed:≤20m/s
Materials
Rotary Ring:Ceramic/SIC/TC
Stationary Ring:Carbon/SIC/TC
Elastomers:NBR/EPDM/VITON
Springs:SSS304/SS316
Metal Parts:SS304/SS316
Mediums
weak acid, weak alkalis, water and solvents.
Customization
Changes of materials for getting other operating parameters are possible. Contact us with your requirements.
