JY3 series mechanical seal,Suitable for Grundfos pumps ,12mm-16mm
| Model NO. | EK-JY3 |
| Balance | Unbalanced |
| Standard | ISO3069, GB6556, DIN24960 |
| Specification | Inner Diameter: 12 mm to16 mm |
| Packaging Details | Carton |
| Payment Terms | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Delivery Time | 2/day |
Views:
We are here to solve your problems in a professional manner
Request ConsultationOur mechanical seal model JY3 is used in Grundfos pumps: CH/CHI / CHE /CRK /SPK /TPAPCR/CRN/NK/ TP/LM (D)/LP(D)/NM/NP/DNM/DNP series.JY3-12mm is suitable for item number of Grundfos: 96409293/96409263 00405096/00405097.JY3-16mm is suitabble for item number of Grundfos:96409265/00485351/00425062/0025063/00425063.We also can make changes as customers'requirement or totally design a new type of mechanical seal to meet clients'needs.
Operating Limits
Pressure:≤2.0MPa
Temperature:-20°C~+150°C
Linear Speed: ≤15 m/s
Materials
Rotary Ring: Carbon/SIC
Stationary Ring: Carbon/SIC/TC
Elastomers: NBR/EPDM/VITON
Spring: SSS304/SS316
Metal Parts: SS304/SS316
Mediums
weak acid, weak alkalis, water and solvents.
Customization
Changes of materials for getting other operating parameters are possible. Contact us with your requirements.
