AL series mechanical seal,Replacement for AESSEAL TO7 TO7D T7X,Burgmann M2N, Roten UNITEN22,Hecker HN 400A ,0.75mm-3mm
| Model NO. | EK-AL |
| Balance | Unbalanced |
| Standard | ISO3069, GB6556, DIN24960 |
| Specification | Inner Diameter: 0.75 mm to 3 mm |
| Packaging Details | Carton |
| Payment Terms | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Delivery Time | 2/day |
Views:
We are here to solve your problems in a professional manner
Request ConsultationOur mechanical seal model AL is mainly applied in ALFA LAVAL LKH Series pump and it can replace the seals for AESSEAL TO7 TO7D T7X,Burgmann M2N, Roten UNITEN22,Hecker HN 400A.We also can make changes as customers'requirement or totally design a new type of mechanical seal to meet clients'needs.
Operating Limits
Pressure:≤0.6 MPa
Temperature: -20°C~+150°C
Linear Speed:≤15m/s
Materials
Rotary Ring: Carbon
Stationary Ring: SIC/TC
Bellows: EPDM
Spring: SSS304/SS316
Metal Parts: SS304/SS316
Mediums
weak acid, weak alkalis, water and solvents.
Customization
Changes of materials for getting other operating parameters are possible. Contact us with your requirements.
